大部分基于JavaScript
的WebSocket
协议示例都是基于nodejs
作为服务端,浏览器作为客户端,很少有nodejs
的客户端实现。同时,由于大部分nodejs
客户端的WebSocket
协议和浏览器原生的WebSocket
并不完全兼容,因此他们无法很好地在一起工作。
本仓库包含了一系列WebSocket
协议在nodejs
下的不同实现,包括纯的TypeScript
语言实现以及Express
或Nestjs
框架的实现。
每个例子在单独的示例文件夹下,其子文件夹用以区分不同的客户端和服务器。
1. Websocket 基础
WebSocket是用于“在网络应用中保持和服务器端进程双边通讯的”,这一功能和传统的http
协议仅能由客户端发起请求服务器进行响应有所区别。 在实现上,websocket协议分为 官方实现 和非官方实现
npmjs
上3个最流行的websocket
库分别是 ws、socket.io、and websocket(其他常见的websocket
库还有WebSocket-Node
、µWebSockets
等). 我们在这里使用了前两个,因为他们各自有其优点和不足。
ws
库是最流行的websoket
库,它完全支持官方协议。在浏览器中可以不用引入额外的包,直接用浏览器原生Websocket
实现功能,然而,如果你要在nodejs
上使用ws
作为客户端,你还需要一个类似像我们这里用的 isomorphic-ws 的包装器。
socket.io
虽然和官方库实现不兼容,但有有其自身的特点,在负载均衡、穿过防火墙以及自动重连方面都有其优势。使用该库时需要在服务器和客户端同时引入,注意,在客户端要引入socket.io-client y库而不是 socket.io
.
2. 示例的基础功能
示例用以说明websocket的不同实现,因此不会实现更复杂的功能共,每个示例在库文件功能允许的情况下包含以下功能,示例中部分代码来自各库的官方示例:
- 一个纯nodejs的服务器或者基于网络框架的服务器
- 一个浏览器实现的客户端和一个nodejs(包含或者不包含框架)实心的客户端
- 运行服务器和客户端(网页浏览器只需要在网页中打开client.html文件),客户端将自动连接服务器
- 客户端连接后,服务器向客户端发送一个
hello
消息,包含hello client
数据 - 客户端收到
message
消息后发送一个response
消息,包含response + 随机数
到服务器 - 服务器收到
response
消息后,发送end
消息并包含其收到的消息内容。 - 客户端收到
end
消息后z延时3秒断开连接 - 服务器和客户端均需要在终端打印其收到的所有消息
- 服务器和客户端均需要打印连接状态变化信息
- 服务器和客户端均需要打印错误信息
3. 示例文件说明
3.1 nodejs ws example
本文件夹包括使用纯nodejs
实现的WebSocket
服务器和客户端示例。 其中server
文件夹包括了服务器文件,安装并通过npm run start
即可编译启动。server
文件夹下还包括了一个运行在http
服务器上的ws
服务器 server2.ts
,通过 npm run start2
启动,为简化示例,两个服务器均使用 18000
端口(http服务器监听3000端口).
client
文件夹包括了:
- 一个纯浏览器的客户端实现
client.html
,使用浏览器打开即可 - 一个使用
ws
实现的客户端client.ts
,运行npm run start
运行 - 一个兼容浏览器标准协议的客户端
client2.ts
,运行npm run start2
运行
说明:
原生ws
和兼容浏览器标准的WebSocket
协议之间的主要区别.在原生ws
中函数格式为
ws.on('message', (message)=>{ console.log('received: %s', message); });
在兼容浏览器标准的WebSocket
协议中书写格式为:
ws.onmessage=(message)=>{ console.log('received: %s', message); }
除此之外,两个协议中message
的类型和内容也不同,原生协议的message
类型为WebSocket.data
,而浏览器标准的协议中message
类型为WebSocket.MessageEvent
,后者的结构类似如下,而前者仅包含其中data
的内容:
MessageEvent { target: [WebSocket], type: 'message', data: '{"event":"end","data":"response: 0.3416359669492526"}' }
3.2 nodejs socketio example
本文件夹包括使用纯nodejs
实现的socket.io
服务器和客户端示例。 其中server
和client
文件夹分别包含了服务器和客户端文件,安装并通过npm run start
即可编译启动。server
文件夹下还包括了一个运行在http
服务器上的socket.io
服务器 server2.ts
,通过 npm run start2
启动,为简化示例,两个服务器均使用 18000
端口.
client
文件夹同时包含了index.html
浏览器客户端,需要注意:
- 由于
socket.io
与标准WebSocket
协议不兼容,因此浏览器需要依赖socket.io.js
文件运行,也可能需要socket.io.js.map
。这两个文件在socket.io
官方库的client-dist
中可以找到。 - 由于版本升级,使用
v2
版本的socket.io
文件连接v3
版本服务器可能会出现400
错误。 - 此外,由于
socket.io v3
开启了CORS
,通过浏览器直接打开index.html
无法正常运行客户端,本案例安装了http-server
库作为网页服务器(默认打开index.html
文件),并在服务器中配置CORS
(见下文),通过npm run startweb
运行http-server
并访问http://localhost:8081
以通过浏览器访问。
说明: 本仓库socket.io v3
,socket.io
从版本2到3的升级过程中有很大变动,因此本仓库示例并不适用于socket.io v2
版本。参考官方文档跟本仓库示例有关的几点说明如下。
- 由于
socket.io v3
代码库使用TypeScript
重写,因此在使用TypeSctipt
时不需要再引入@types/socket.io
或@types/socket.io-client
库,如果继续引入可能会在编译时出错。 - 在版本3中,跨域请求
CORS
需要在新建服务器时明确声明,例如:
const io = require("socket.io")(httpServer, { cors: { origin: "https://localhost:8081", credentials: true, methods: ["GET", "POST"] } });
socket.io
通讯可配置自动重连机制,该机制默认打开,在服务器连接断开后会自动尝试重连服务器,如果要测试该功能,可注释掉客户端setTimeout
函数内容,关闭服务器后再打开,客户端即可重新连接。socket.io
支持消息确认机制,本示例的response
消息增加了消息确认机制,服务器在收到消息后会通过回调函数进行确认。socket.io
消息的内容类型可兼容string
或JSON
等格式,用户需要在编程时自行决定数据类型并尽心解析。
3.3 nestjs ws example
本文件夹基于ws
库使用流行的nestjs
框架分别实现了服务器和客户端的WebSocket
服务,由于Nestjs
是一个服务器框架,因此,在客户端部分,又通过nestjs
内置的静态文件和mvc
框架服务设计了一个html
网页以便进行功能测试。本文件夹案例和 1. nodejs ws example
文件夹中的案例接口设计基本相同,可以互相连接,但本案例为了丰富功能测试,在功能上进行了以下修改和补充:
- 服务器在收到客户端的
response
消息后,并不会立即返回end
消息,而是同样返回一个response
消息,以避免客户端过早断开连接影响测试。 - 客户端新增了一个
response
消息响应,将收到的消息进行打印显示 - 客户端新增了一个
terminate
消息,需要手动触发以发送,服务器收到terminate
消息后,发送end
消息,客户端再断开连接
为了测试客户端的http
相应功能,在客户端新增了两个api
分别为,为了避免客户端和服务器http端口冲突,修改客户端端口为3001: –Get http://localhost:3001/ws-client/getdata
用于发送并接受response
消息,通过随机数来更新数据 –Get http://localhost:3001/ws-client/sendTerminate
用于发送terminate
消息以断开连接,该命令会停止客户端程序运行
在客户端根目录下新建了client.http
文件,该文件可以通过vscode
的REST Client
插件运行,用于进行api功能调试。
经过测试,ws
库可以不需要http
服务器启用cors
功能。
使用步骤:
- 分别在
server
和client
文件夹下运行npm run start
即可启动服务器和客户端,可以看到websocket通讯。 - 在浏览器中打开
http://localhost:3001
可以在console
中和网页中看到数据,通过刷新按钮可以刷新数据。 - 本示例和
1. nodejs ws example
中的示例可以互通互联,但由于api
不同,使用时应注意区别。
3.4 nestjs socket io example
本文件夹基于socket.io
库使用流行的nestjs
框架分别实现了服务器和客户端的WebSocket
服务, API接口和示例3完全相同,但有一些 重点注意事项:
- 由于
socket.io
的3.x和2.x版本不兼容,他们无法协同工作,也就是说服务器和客户端要工作在同一个大版本下。本案例使用版本3. Nestjs
内置的socket.io
库@nestjs/platform-io
是基于socket.io
版本2,与版本3的客户端不兼容。Nestjs
作者答应在nestjs 8
中升级socket-io
版本,目前,如果要像本示例一样使用socket.io v3
,可以参考nestjs issue 5676问题中给出的临时策略, 用socket-io.adapter
而不是官方的适配器。(要删除cookie项下面的name
一行) .- 当然,将客户端降级到2.x版本可能也能工作,但本案例并未尝试此种做法。
- 到目前为止,客户端和服务器可以正常连接工作,但是如果使用案例2中的客户端,是连接不上本案例的服务器的,这可能是由
@WebSocketGateway()
装饰器造成的,必须把装饰器的port
参数留空,或者配置为和服务器http
端口一致,才可以正常访问,如果两者不一致,即使配置了cors
仍然是无法通过案例2中的客户端访问本案例中的服务器的。
参考资料
- HTML在线标准
- 官方WebSocket协议
- ws库
- socket.io 库
- websocket 库
- isomorphic-ws 库
- socket.io-client 库
- socket.io 网站版本迁移说明
- Nestjs issue 5676
Most WebSocket Examples in JavaScript are of nodejs in server side and web brawser in client side, and not that easy to move these client to a nodejs implementation. Besides, as most nodejs WebSocket client are not compatible with native brawser WebSocket client, few examples can work well both in nodejs and web brawser.
This repository contains a list of examples to illustrate the implementation of WebSocket protocal in nodejs, both pure TypeScript or with frameworks like Express or Nestjs.
Each example folder contains independent example, with subfolders to distinguish server and client.
1. Websocket Basics
WebSocket is “To enable web applications to maintain bidirectional communications with server-side processes”, there are official implementation and unofficial ones.
The top three popular websocket libraries on npmjs are ws、socket.io、and websocket( There are also other implementations like WebSocket-Node
or µWebSockets
). We use both ws and socket.io in this repository because they each has there advantages and disadvantages.
The ws
library is the most popular one and it is fully compatible with the Official WebSocket
protocal, however, if you want to use ws
as client in nodejs, a wrapper like isomorphic-ws is necessary, which is also used in the examples.
The socket.io
library has its own features like load balance and auto-reconnection functions although it is not compatible with the Official WebSocket
protocal and you need to install it both in server side and client side. In client side, you need socket.io-client library instead of socket.io
.
2. Basic Example Functions
The examples are used to illustrate implementations of websocket, thus no complex functions will not be apllied here. The basic functions of each example contains following functions (unless the library has no relative function),and some of the example code are from original library examples:
- A websocket server in pure nodejs or with a http framework
- Two websocket client in brawser and in nodejs (with or without framework)
- Start both server and client side(open the html file in a web brawser for the brawser client), the client will try to connect to the server
- When the client connect to the Server, the server send an
message
event withhello client
to the client - When the client receives the
message
event, it send anresponse
event withresponse + randmon number
to the server - When the Server receives the
response
event, it send anend
event with the content it received. - When the Client receives the
end
event, it closes the connection after 3s delay. - Both server and client print every event content it received in the console.
- Both server and client print the connect and disconnect status change in the console.
- Both server and client print error messages in the console.
3. Examples
3.1 nodejs ws example
This example contains WebSocket server and client example implemented with nodejs. The server folder contains a normal server ,install and run npm run start
to start it. There is another ws
server wrapped in a httpServer
in the server folder named server2.ts
, run npm run start2
to start it, to make the example simple, the two servers run on the same port 18000
(the http server listens port 3000).
client
folder contains:
- A pure brawser client
client.html
, open with a brawser to start - A
ws
client with native ws library, runnpm run start
- A
ws
client compatible with native WebSocket protocol, runnpm run start2
Note:
The function format are different from ws
and native WebSocket, in ws
library:
ws.on('message', (message)=>{ console.log('received: %s', message); });
In native WebSocket compatible format:
ws.onmessage=(message)=>{ console.log('received: %s', message); }
Besides, the message
in the two protocols are also different, in the ws
library it is WebSocket.data
while in the native WebSocket protocol is WebSocket.MessageEvent
, the latter structure is similar as below as the former contains only the data
part.
MessageEvent { target: [WebSocket], type: 'message', data: '{"event":"end","data":"response: 0.3416359669492526"}' }
3.2 nodejs socketio example
This example contains socket.io
server and client implemented with nodejs
. Install and npm run start
in server and client folder to start each. There is another socket.io
server wrapped in a httpServer
in the server folder named server2.ts
, run npm run start2
to start it, to make the example simple, the two servers run on the same port 18000
There is also a index.html
file which implemented a brawser client:
- As socket.io is not compatible with native WebSocket, there is a
socket.io.js
file (asocket.io.js.map
may also needed, both files can be found onsocket.io
libraryclient-dist
folder) which is replied by the html file. - Using the obsolete
socket.io.js v2
file to connectv3
server may cause400 error
. - As
socket.io v3
usesCORS
, simply open theindex.html
file in a brawser cannot visit the server. We installedhttp-server
here (which uses index.html as default page), and config theCORS
option in the server (see below), runnpm run startweb
and visithttp://localhost:8081
in a brawser to connect to the server.
NOTICE:
This repository uses socket.io v3
and not compatible with socket.io
. See Socket.io Document for the detailed differences between the two version. Some import feature are as follows:
- As
socket.io v3
is rewritten byTypeScript
, there is no need to import@types/socket.io
or@types/socket.io-client
library to usesocket.io
inTypeSctipt
, import the above libraries in your code may cause mistake. CORS
needs to be explicitly announced as follows:
const io = require("socket.io")(httpServer, { cors: { origin: "https://example.com", methods: ["GET", "POST"] } });
socket.io
support autoreconnection mechanism which is enabled by default, if you want to test the function, just comment thesetTimeout
function in client, stop and start the server again, the client will reconnect to the server automatically.socket.io
support message acknowledgement mechanism, theresponse
event in this example added it, the server will give an acknowledgement message through callback function when it receives a response message.- The content of
socket.io
event are highly customised ,you need to decide and encode/decode the content and avoid possible mistakes.
3.3 nestjs ws example
This example contains both WebSocket server and client implementation with popular Nestjs
framework using ws
library. As Nestjs is a server framework itself, a html
file is added with nestjs serve Static function and MVC service. the communication interfaces in this example is similar to 1. nodejs ws example
, so the servers and clients can connect with each other. However, for test purpose, the functions a modifed in this example so as to keep the client keep connected with the server until there is an order to terminate:
- The server will not send an
end
message when it received aresponse
message, instead, it sends a sameresponse
message to the client. - A
response
message listener is added to the client, it will print the message it received. - A
terminate
message will be send from the client trigged by a http requestsendTerminate
, the server will send the oldend
message when it received theterminate
message.
The client httpServer works on port 3001, two apis were added to update data and terminate connection –Get http://localhost:3001/ws-client/getdata
to send response
and update the data it received. –Get http://localhost:3001/ws-client/sendTerminate
用to send terminate
message,This will also terminate the client app, you need restart it again
A client.http
file is created in client folder to test http requests, which can be used by vscode
plugin REST Client
.
no cors
configuration when use ws
library.
To Use:
- In the
server
andclient
runnpm run start
to start them and see the result. - In a brawser visit
http://localhost:3001
, to see and update data in console and in the page. - To work with
1. nodejs ws example
servers and clients, you need to pay attention to the API difference.
3.4 nestjs socket io example
This example contains both WebSocket server and client implementation with popular Nestjs
framework using socketio
library. The program structure and API interface are exactly the same as example 3. Except for some important NOTES:
- As
socket.io
version 3.x and 2.x are incompatible, they cannot work together, which means the server and client shall of the same major version. Nestjs
built-insocket.io
library@nestjs/platform-io
was written with socket.io version 2, so it is incampatible with a version 3 client.- The
Nestjs
author promised to updatesocket-io
on nestjs 8 ,however, if you want to usesocket.io v3
in nestjs, a temporary approach is introduced in nestjs issue 5676, use thesocket-io.adapter
in the issue (thename
line under cookie shall be removed) instead of the official one. This is the way we used here. - You may also downgrade the client version to v2.x ,however, we did not try that way here.
- SO FAR, the server and client works well in this example, but if you want the server in this example works together with the client in example 2, there is still a problem, perhaps due to the
@WebSocketGateway()
decorator mechanism, you will not visit the server if theport
parameter (for example@WebSocketGateway(18000)
) is different from the server http port (for example app.listen(3000)) even if cors is enabled. You shold leave the@WebSocketGateway()
decorator blank and use the client to visit the same http port.
